Projector NEC NEC ME383W, 1280 x 800 (WXGA) , 3800 ANSI, LCD, 16000:1
Projector NEC NEC ME383W, 1280 x 800 (WXGA) , 3800 ANSI, LCD, 16000:1
w/ VAT
w/ VAT
Online leasing
|
monthly payment
|
monthly payment |
|
|---|---|---|
| 3 payments |
|
- |
| 6 payments |
|
|
| 9 payments |
|
|
| 12 payments |
|
|
| 15 payments |
|
|
| 24 payments |
|
|
Projection Technology 3LCD Technology
Native Resolution 1280 x 800 (WXGA)
Aspect Ratio 16:10
Contrast Ratio 16000:1
Brightness 3800 High Bright ANSI Lumens
Lamp 225 W AC (151 W AC Eco Mode)
Lamp Life [hrs] 10000 (20000 Eco Mode)
Keystone correction +/- 30° manual horizontal / +/- 30° manual vertical
Projection Angle [°] 6.6 - 11.1
Projection Factor 1.2 – 2.1 : 1
Projection Distance [m] 0.94 – 11.59
Screen Size (diagonal) [cm] / [inch] Maximum: 762 / 300"; Minimum: 76 / 30"
Zoom Manual
Focus Adjustment Manual
Supported Resolutions 3840x2160 @ 30hz digital;1280x800 (Maximum resolution of analog input)
RGB (analog) Input: 1 x Mini D-sub 15-pin, compatible to component (YPbPr)
Output: 1 x Mini D-sub 15 pin
Digital Input: 2 x HDMI™ (Deep Color, Lip sync)
Video Input: 1 x RCA
Audio Input: 2 x 3.5 mm Stereo Mini Jack; 2 x RCA Stereo
Output: 1 x 3.5 mm Stereo Mini Jack
Control Input: 1 x D-Sub 9 pin (RS-232) (male)
LAN 1 x RJ45; Optional WLAN
USB 1 x Type A (USB 2.0 high speed); 1 x Type B
Video Signals NTSC; PAL; PAL60; SECAM
Power Supply 100-240 V AC; 50 - 60 Hz
Power Consumption [W] 288 (High Bright) / 196 (Eco) / 1.5 (Network Stand-by) / 0.5 (Stand-by)
Dimensions (W x H x D) [mm] 345 x 104.6 x 261 (without lens and feet)
Weight [kg] 3.2
Fan Noise [dB (A)] 29 / 37 (Eco / Normal)
Special Characteristics Auto Eco Mode; Auto Power ON/OFF; Carbon Savings Meter; Colour Management; Content Transmission via Network; Crestron RoomView; DICOM Simulation; Direct Power-Off Function; High Altitude Mode; Kensington security slot; Keypad Lock; Keystone Correction (H=±30°, V=±30°); Lens Cover; Magnify; NaViSet Administrator 2; Off-Timer; Optional User Logo; Optional WLAN; OSD with 29 languages; Password Security System; Quick On/Off; RS-232 Control; Security Bar; USB Display; USB Viewer for JPEG; Virtual Remote for direct PC control; Wall Colour Correction
Projectors 3 years pan-European service
Light Source 6 months, max. 1000 hrs
Optional Accessories Lamp (NP47LP); Universal Ceiling Mounts (PJ01UCM); Wireless LAN module NP05LM2 (Europe),
| Manufacturer | NEC |
| Warranty | 36 months |
| Product code | 60005220 |
| Barcode | 5028695614338 |
| Technology |
LCD
|
| Light Source |
Lamp
|
| Type |
Portable
|
| Brightness (ANSI lumens) |
3800 lm
|
| Aspect Ratio |
16:10
|
| Native Resolution |
1280 x 800
|
| Resolution Support |
Up to 1920 x 1080
|
| Contrast |
16000:1
|
| Short Throw |
No
|
| Projection Distance |
94 – 1159 cm
|
| Min. Diagonal (m) |
0.76
|
| Max. Diagonal (m) |
300"
|
| Lamp Life (hours) |
10000 SmartEco / 6000 Eco / 4500 Normal
|
| Features | |
| Horizontal Scan Rate (kHz) |
15 - 100
|
| Vertical Scan Rate |
50 - 120
|
| Interface |
RGB (analog) Input: 1 x Mini D-sub 15-pin, compatible to component (YPbPr) Output: 1 x Mini D-sub 15 pin; Digital Input: 2 x HDMI™ (Deep Color, Lip sync); Video Input: 1 x RCA; Audio Input: 2 x 3.5 mm Stereo Mini Jack; 2 x RCA Stereo Output: 1 x 3.5 mm
|
| Displayable Color | |
| Speakers |
1 x 16 (mono)
|
| Remote Control |
Yes
|
| Power Consumption |
225 W AC (151 W AC Eco Mode)
|
| Noise Level |
29 / 37 (Eco / Normal)
|
| Other | |
| 3D |
No
|
| LAN |
Ethernet
|
| 4K |
No
|
| Dimensions |
345 x 104.6 x 261 (without lens and feet)
|
| Accessories | |
| Weight | 0.000 kg |
| me383w.pdf | PDF, 119.3 KB | Download |
