Power Supply ASUS ROG THOR III 3000W Edition 20, 80+ Titanium PCIe 5.1, Fully Modular
| Manufacturer | ASUS |
| Warranty | 120 months |
| Product code | 90YE00VA-B0NA00 |
| Barcode | 4711636587181 |
| Wattage (W) |
3000 W
|
| Form Factor |
ATX 3.1
|
| Connectors |
1 x 20+4 PIN
10 x SATA
3 x PCI-Express 6+2-pin
3 x CPU 4+4 Pin
3 x 4 Pin Peripheral
PCI-E 16-pin x 4 (12V-2x6/ROG EQUALIZER)
|
| Sertificate |
80 PLUS® Titanium
|
| Modular |
Yes
|
| PFC |
Active PFC
|
| Efficiency |
92%
|
| Fan Size |
140 mm
|
| Dimension |
190 x 150 x 86 mm
|
| Input Voltage |
100 - 240 VAC
|
The ASUS ROG Thor 3000W Titanium III Edition 20 is an ultra-flagship power supply built to celebrate two decades of Republic of Gamers innovation, representing the absolute peak of modern power delivery. Engineered with server-grade GaN MOSFET technology and an adaptive dual-voltage design, it outputs an unprecedented 3000W of power on 220–240V setups to comfortably drive extreme multi-GPU workstations and high-end gaming rigs. Featuring revolutionary thermals, custom cables that actively reduce heat, and intelligent voltage stabilization, this unit delivers unmatched efficiency, stability, and control for the most demanding PC configurations.
Extreme Power Output: Features a Dual-Voltage Adaptive Design that delivers a massive 3000W of clean continuous power on standard 220–240V grids (and up to 1600W on 110–120V setups), offering enough headroom to support up to four high-end GPUs like the GeForce RTX 5090.
ROG Equalizer Cable System: Includes patented ROG Equalizer 12V-2x6 PCIe power cables designed to intelligently manage current distribution, keeping connector temperatures significantly cooler and extending the lifespan of critical graphics hardware.
Server-Grade Efficiency: Incorporates advanced GaN (Gallium Nitride) MOSFETs to achieve 80 PLUS Titanium certification, reducing power loss, increasing energy efficiency by up to 30%, and lowering heat buildup inside the chassis.
GPU-First Intelligent Voltage Stabilizer: Utilizes a patented hardware voltage stabilizer to improve power delivery directly to the graphics card by up to 45%, providing rock-solid voltage lines during extreme overclocking and heavy load spikes.
Magnetic OLED Display & Extender: Outfitted with a detachable magnetic OLED panel that lets you monitor real-time wattage draw and efficiency stats, which can be attached directly to the PSU or positioned on your desk or case using the included USB-C extension cable.
Advanced Thermal Architecture: Combines heavy-duty custom ROG heatsinks, a fully aluminum enclosure, gold-plated high-performance copper pins, and a long-life dual-ball bearing fan with 0dB technology for near-silent operation under lower workloads.
Next-Gen Standards & Cables: Fully compliant with ATX 3.1 and PCIe 5.1 standards to handle high dynamic power excursions gracefully, accompanied by ultra-flexible sleeved modular cables for clean and effortless routing.
