Description

Key Features
Ports:

16 × 10/100 Mbps PoE RJ-45 ports

2 × 10/100/1000 Mbps RJ-45 uplink ports

2 × 1000 Mbps SFP uplink ports (combo with RJ-45)

PoE specifications:

Ports 1–2: up to 90W (support IEEE802.3bt/Hi-PoE)

Ports 3–16: up to 30W

Total PoE budget: up to 240W

Supported standards: IEEE802.3af, IEEE802.3at, IEEE802.3bt, Hi-PoE

Management and features:

Web interface (HTTP/HTTPS)

SNMP v1/v2c/v3

VLAN (802.1Q), STP/RSTP, LACP, port mirroring

QoS: 802.1P, DSCP, WRR

PoE Watchdog, Green PoE, PoE power management

Performance:

Switching capacity: 8.8 Gbps

Forwarding rate: 5.36 Mpps

Buffer memory: 2.75 Mb

MAC table: 4K addresses

Additional features:

PoE transmission distance up to 250 meters

Surge protection: 4kV (common mode), 2kV (differential mode)

Operating temperature: -10°C to +55°C

Dimensions: 440 × 300 × 44 mm

Weight: approximately 3.5 kg

? Applications and compatibility

This switch is ideal for:

IP ​​video surveillance with high power consumption (e.g. PTZ cameras)

Access control systems

Network environments requiring flexible PoE power supply and reliability

Compatible with PoE extenders such as the Dahua PFT1300, which allows for extending the range of PoE power.
