Technical details

    Connectors:
    1 x USB 2.0 Type-A male
    1 x 3.5 mm 4 pin stereo jack female (CTIA standard)
    Chipset: KT02F20 + MAX97220A
    Supported sample rates: 44.1 / 48 / 96 kHz (depending on the system and the connected devices)
    LED indicator for sampling rates
    USB audio device specification 1.0
    Up to 24 Bit / 96 kHz sampling rate for playback and 24 Bit / 48 kHz for recording
    Signal-to-noise ratio (SNR): ca. 103 dB
    Frequency response: 20 Hz - 20 kHz +/- 0.5 dB
    Total Harmonic Distortion + Noise (THD+N): 0.003 % @ 1 mW
    Headphone-Drive Ability: 16 - 300 Ohm
    USB bus powered
    Plug & Play
    Dimensions (LxWxH): ca. 41.8 x 17.2 x 9.8 mm
