Description

Scanner Type:    Bi-directional
Light Source:    650 nm visible laser diode
Scan Rate:    100 scans per second typical
Nominal Working Distance:    From contact to 43 cm or 100% U.P.C/EAN symbols
Print Contrast:    20% minimum reflective difference
Roll (Tilt):    +/- 30 degrees
Pitch:    +/- 65 degrees
Skew (Yaw):    +/- 60 degrees
Decode Capability:    U.P.C/EAN, U.P.C/EAN with supplementals, UCC/EAN 128, Code 39, Code 39 Full ASCII,
                                  Code 39 TriOptic, Code 128, Code 128 Full ASCII, Codabar, Interleaved 2 of 5,
                                   Discrete 2 of 5, Code 93, MSI, Code 11, IATA, RSS variants, Chinese 2 of 5
Interfaces Supported:    RS232, Keyboard Wedge, Wand, IBM 468X/9X, USB, Synapse and Undecoded

Dimensions: 15.2 cm H x 6.3 cm W x 8.4 cm
Weight: 146 gm
Voltage: 5 volts +/- 10%
Current: 130 mA typical, 175 mA max
Power Sources: Host power or external power supply
