Description

- One USB-PS/2 console controls 8 computers; Cascade up to 2 levels - control up to 64 computers
- Broadcast mode - operations simultaneously performed on all selected computers, software installation and upgrading, system wide shutdown, etc.
- Computer selection via front panel pushbuttons, hotkeys and multilingual on-screen display (OSD) menu
- Video DynaSync - Exclusive ATEN technology eliminates boot-up display problems and optimizes resolution when switching between ports

Computer Connections:
    Direct:    8
    Maximum:   64 (via Cascade)
Port Selection:    OSD, Hotkey, Pushbutton
Connectors:
    Console Ports:    1 x SPHD-18 Male (Yellow)
    KVM Ports:    8 x SPHD-15 Female (Yellow)
    Firmware Upgrade:    1 x RJ-11 Female (Black)
    Power:    1 x DC Jack
Switches:
   Ports:    8 x Pushbutton
   Firmware Upgrade:    1 x Slide
LEDs:
    Online:    8 (Orange)
    Selected:    8 (Green)
    Power:    1 (Dark Green)
Emulation:
    Keyboard / Mouse:    PS/2, USB
    Video:    2048 x 1536; DDC2B
Dimensions:    43.72 x 16.13 x 4.40 cm
