Description

Supported operating systems
Windows 8 / 8.1 (32-bit / 64-bit), Windows 7 (32-bit / 64-bit), Windows Vista (32-bit / 64-bit), Windows Server 2012 R2 (64-bit), Windows Server 2012 (32-bit / 64-bit), Windows Server 2008 R2 (64-bit), Windows Server 2008 (32-bit / 64-bit)

Scanner Type:  ADF (Automatic Document Feeder)

Scanning modes:  Simplex / Duplex, Color / Grayscale / Monochrome

Image Sensor Type:  Single line CMOS-CIS x 2 (Front x 1, Back x 1)

Light Source:  R, G, B LED x 2 (Front x 1, Back x 1)

Document size:
Maximum: A4 Portrait (210 x 297 mm) or Legal (8.5 x 14 in.) or 8.5 x 34 in. (215.9 x 863.6 mm) (long page scanning: 3,048 mm (120 in.))
Minimum: A8 Portrait / Landscape (52 x 74 mm)

Paper weight (Thickness):
Paper:
50 to 209 g/m2 (0.06 to 0.26 mm)
* A8 size: 127 to 209 g/m2 (0.15 to 0.26 mm)
Plastic Card:
ISO7810 ID-1 type compliant (0.76 mm or less, embossed plastic cards with total thickness of 1.24 mm or less)

Scanning speed (A4, Portrait):
Simplex: 30 ppm (200 dpi / 300 dpi)
Duplex: 60 ipm (200 dpi / 300 dpi)

Paper chute capacity (A4 Landscape):  50 sheets (A4: 80 g/m2 or 20 lb)

Expected daily volume:  3,000 sheets/day

Background colors:  White (Hardware, scanned background is gray)

Optical Resolution:  600 dpi

Output Resolution:  50 dpi to 600 dpi (adjustable by 1 dpi increments), 1,200 dpi (driver) (5)

Output format:  Color: 24-bit, Grayscale: 8-bit, Monochrome:1-bit

Interface:  USB2.0 B type, Ethernet(10BASE-T,100BASE-TX,1000BASE-T)

Image processing function
Auto color detection, Automatic page size detection, De-Skew, Multi-image, Blank page skip, Error diffusion, Dropout color (R, G, B, Saturation), Image emphasis, Advanced DTC, sRGB, Halftone, Smoothing, Split image, Vertical streaks reduction, Digital endorser, Edge correction, Dynamic threshold(iDTC)

Power requirement:  AC 100 V to 240 V 10%

Power consumption:
Operating: 18 W or less
Sleep mode: 1.6 W or less
Auto standby (OFF) mode: 0.4 W or less

Operating environment:
Temperature: 5 to 35 C (41 to 95 F)
Relative humidity: 20 to 80% (Non-condensing)

Dimensions:  298 mm x 135 mm x 133 mm (11.7 in. x 5.3 in. x 5.2 in.)

Weight:  2.5 kg

Included software / drivers:
PaperStream IP drivers (7) (PaperStream IP (TWAIN), PaperStream IP (TWAIN x64), PaperStream IP (ISIS) ), Software Operation Panel, Error Recovery Guide, Presto! PageManager, ABBYY FineReader Sprint, Scanner Central Admin Agent

Environmental compliance
ENERGY STAR and RoHS

Others:
Long page scanning:  3,048 mm (120 in.)
