Description

- One dual-view USB / HDMI console controls two DisplayPort computers and two USB 3.1 Gen 1 peripherals
- Two PC Operation Modes:
     Single PC Mode – allows content of the PC with current KVM focus to be displayed over both monitors
     Dual PC Mode – allows content of two PCs to be displayed separately on two monitors regardless of the KVM focus
- Supports superior video quality – resolutions up to 4K DCI (4096 x 2160 @ 60 Hz)
- Boundless Switching – allows the mouse cursor to move across screen borders for quick switching between video sources

Computer Connections:    2
Console Ports:    2 x USB Type A Female
                               2 x HDMI Female (Black)
                               2 x 3.5mm Audio Jack Female (Green; 1 x front, 1 x rear)
                               2 x 3.5mm Audio Jack Female (Pink; 1 x front, 1 x rear)
KVM (Computer) Ports:    2 x USB3.1 Gen1 Type B Female (Blue)
                                           4 x DisplayPort Female (Black)
                                           2 x 3.5mm Audio Jack Female (Green)
                                           2 x 3.5mm Audio Jack Female (Pink)
Remote Port Selector:    1 x 2.5mm Audio Jack Female
Power:    1 x DC Jack
USB Hub:    2 x USB3.1 Gen1 Type A Female (Blue; 1 x front; 1 x rear
LEDs:    Audio:    2 (Green)
                KVM:    2 (Orange)
                USB:    2 (Green)
Keyboard / Mouse:    USB
Video:    4096 x 2160 @ 60Hz
