Description

Allows up to eight HDMI sources to be connected to one HDMI display
Quick and easy switching between HDMI sources via front panel pushbuttons or IR remote control
Superior video quality - HDTV resolutions of 480p, 720p, 1080i, 1080p (1920x1080); VGA, SVGA, SXGA, UXGA, and WUXGA (1920x1200)
Built-in bi-directional RS-232 serial port for high-end system control

Video Input
   Interfaces:   8 x HDMI Type A Female (Black)
   Impedance:   100 Ω
   Max. Distance:   3m @1920X1080@60 (4:4:4)
Video Output
   Interfaces:   1 x HDMI Type A Female (Black)
   Impedance:   100 Ω
   Max. Distance:   15m @1920X1080@60 (4:4:4)
Video
   Max. Data Rate:   6.75 Gbps (2.25 Gbps Per Lane)
   Max. Pixel Clock:   225 MHz
   Compliance:   HDMI (3D, Deep Color)
                         HDCP Compatible
                         Consumer Electronics Control (CEC)
  Max. Resolution:   Up to 1080p
Audio
   Input:   8 x HDMI Type A Female (Black)
   Output:   1 x HDMI Type A Female (Black)
Control:   RS-232

Dimensions:   43.70 x 15.98 x 4.40 cm
Weight:   1.75 kg
