Description

- Built-in advanced USB-C E-Mark integrates USB4, Thunderbolt 3 and Thunderbolt 4 compatibility
- Backwards compatible with USB 3.2/3.1
- Features a 4K HDMI output, supporting video resolutions up to 3840 x 2160 at 60 Hz
- Maximize your gaming experience with 1920 x 1080 @ 144 Hz refresh rate
- Extending one display up to 3840 x 2160 @ 60, easily switch to a higher refresh rate of 2560 x 1440 @ 120 Hz via HDMI port to enjoy your gaming under Windows OS
- Three SuperSpeed USB 10Gbps downstream ports (1 USB-C and 2 Type-A) to connect peripherals
- Charge and power connected laptop and peripherals with 100W Power Delivery
- Easily add a wired network connectivity with the Gigabit Ethernet port
- Plug-and-play, no driver installation required

host connector:   1 - USB-C Male
network interface:   RJ45 (Gigabit Ethernet)
ports:   1 - USB-C SuperSpeed 10Gbps with Power Delivery 3.0
         2 - USB Type-A SuperSpeed 10Gbps
         1 - 4K HDMI
         1 - RJ45 Gigabit Ethernet
power source:   Bus-powered or self-powered
video output:   1 - HDMI Female
audio channel:   2.1 via HDMI
compatible networks:   10/100/1000 Mbps
displays supported:   1
max data transfer rate:   10Gbps
max display refresh rate:   3840 x 2160 @ 60 Hz
                            2560 x 1440 @ 120 Hz
                            1920 x 1080 @ 144 Hz
                            (Windows®)
max display resolution:   3840 x 2160
input current:   Up to 5A
input voltage:   Up to 20V
output current:   Up to 4.5A
output voltage:   Up to 20V
power delivery:   Up to 100W via USB-C
