Description

Connectors:
Input: 1 x DisplayPort 20 pin male
Output: 2 x HDMI-A 19 pin female
Chipset: STDP4320
DisplayPort 1.2a and High Speed HDMI specification
Active converter, Single- / Multi-Stream Transport Hub (SST / MST)
Functions: Mirrored or Extended (Windows only)
Maximum resolution (depending on the system and the connected hardware):
DisplayPort 1.1 or 1.2 Single-Stream Transport (SST):
up to 1920 x 1080 @ 60 Hz (mirror)
DisplayPort 1.2 Multi-Stream Transport (MST):
up to 3840 x 2160 @ 30 Hz (mirror or extended)
Supports 3D displays
Supports HDCP 1.3
Supports Eyefinity / Single Large Surface (SLS)
Audio input formats: 7.1 channel up to 192 kHz sample rate
Metal housing
Colour: black
Cable length without connectors: ca. 30 cm
Dimensions (LxWxH): ca. 100 x 65 x 23 mm
