Description

Size:  80x80x25 mm
Mounting hole spacing:  71.5x71.5 mm
Connector & pin-configuration:  4-pin PWM
Cable length:  20cm + 30cm NA-EC1 extension cable
Bearing:  SSO2
Blade geometry:  A-Series with Flow Acceleration Channels
Rotational speed (+/- 10%):  2200 RPM
Rotational speed with L.N.A. (+/- 10%):  1750 RPM
Min. rotational speed (PWM, +/-20%):  450 RPM
Airflow:  55.5 m³/h
Airflow with L.N.A.:  43.9 m³/h
Acoustical noise:  17.7 dB(A)
Acoustical noise with L.N.A.:  13.8 dB(A)
Max. input power:  0.96 W
Max. input current:  0.08 A
Operating voltage:  12 V
MTTF:  > 150.000 h
