Description

Size:  120x120x25 mm
Mounting hole spacing:  105x105 mm
Connector & pin-configuration:  4-pin PWM
Cable length:  20cm + 30cm NA-EC1 extension cable
Bearing:  SSO2
Blade geometry:  Heptaperf™
Rotational speed (+/- 10%):  1500 RPM
Rotational speed with L.N.A. (+/- 10%):  1200 RPM
Min. rotational speed (PWM, +/-20%):  300 RPM
Airflow:  93.4 m³/h
Airflow with L.N.A.:  74.3 m³/h
Acoustical noise:  22.4 dB(A)
Acoustical noise with L.N.A.:  18.6 dB(A)
Max. input power:  0.6 W
Max. input current:  0.05 A
Operating voltage:  12 V
MTTF:  > 150.000 h
