Description

Size:  120x120x25 mm
Mounting hole spacing:  105x105 mm
Connector & pin-configuration:  3-pin
Cable length:  20cm + 30cm NA-EC1 extension cable
Bearing:  SSO2
Blade geometry:  A-Series with Flow Acceleration Channels
Frame technology:  AAO (Advanced Acoustic Optimisation)
Material:  Sterrox® LCP
Rotational speed (+/- 10%):  2000 RPM
Rotational speed with L.N.A. (+/- 10%):  1700 RPM
Rotational Speed with U.L.N.A. (+/- 10%):  1350 RPM
Airflow:  102.1 m³/h
Airflow with L.N.A.:  84.5 m³/h
Airflow with U.L.N.A.:  64.5 m³/h
Acoustical noise:  22.6 dB(A)
Acoustical noise with L.N.A.:  18.8 dB(A)
Acoustical noise with U.L.N.A.:  14.2 dB(A)
Max. input power:  1.68 W
Max. input current:  0.14 A
Operating voltage:  12 V
MTTF:  > 150.000 h
