Description

Size:  140x140x25 mm
Mounting hole spacing:  124.5x124.5 mm
Connector & pin-configuration:  4-pin PWM
Cable length:  40cm
Bearing:  SSO2
Blade geometry:   A-Series with Flow Acceleration Channels
Frame technology:  AAO
Material:  Fibre-glass reinforced polyamide
Ingress protection:  IP52
Motor type:  Three-phase
Rotational speed (+/- 10%):  3000 RPM
Min. rotational speed (PWM, +/-20%):  800 RPM
Airflow:  269.3 m³/h
Acoustical noise:  41.3 dB(A)
Max. input power:  6.6 W
Max. input current:  0.55 A
Operating voltage:  12 V
MTTF:  > 150.000 h
